# Note that this technique no longer works due to a change on the rules for the slot vs hole diameter dimensions. #
Illustrating a way to make a Castellated slot using the Slot tool:
1) Place the required number of pads then position and dimension them as required
2) Turn each pad into a slot of the desired dimensions.
The end result should look like the slot on the far right.
Note that in t...
