Bally Astrocade RGB

2 years ago 379
  • Description
  • Documents
  • BOM
  • Attachments
  • Members
  • Comments

Description

Documents

Sheet_1

BOM

ID Name Designator Footprint Quantity Manufacturer Part Manufacturer Supplier Supplier Part Price LCSC Assembly Mounted BOM_Supplier BOM_Manufacturer BOM_Manufacturer Part BOM_Supplier Part
1 R-Y P1 HDR-1X1/2.54 1 LCSC ReliaPro Header-Male-2.54_1x1 C81276
2 B-Y P2 HDR-1X1/2.54 1 LCSC ReliaPro Header-Male-2.54_1x1 C81276
3 Y P3 HDR-1X1/2.54 1 LCSC ReliaPro Header-Male-2.54_1x1 C81276
4 +12V P4 HDR-1X1/2.54 1 LCSC ReliaPro Header-Male-2.54_1x1 C81276
5 +5V P5,P9 HDR-1X1/2.54 2 LCSC ReliaPro Header-Male-2.54_1x1 C81276
6 -5V P6 HDR-1X1/2.54 1 LCSC ReliaPro Header-Male-2.54_1x1 C81276
7 GND P7,P8 HDR-1X1/2.54 2 LCSC ReliaPro Header-Male-2.54_1x1 C81276
8 1u C1,C2,C3,C5 RAD-0.1 4
9 160 R24,R15,R23 AXIAL-0.3 3
10 1k R25,R10,R16,R17,R22,R9,R26,R27,R28 AXIAL-0.3 9
11 100 R21 AXIAL-0.3 1
12 1m L1,L2 AXIAL-0.4 2
13 1N52328 D1 SOD-123 1 LCSC ON MBR0520LT1G C23848
14 12k R18 AXIAL-0.3 1
15 3k R5,R4,R3 AXIAL-0.3 3
16 1.2k R20 AXIAL-0.3 1
17 620k R19 AXIAL-0.3 1
18 2N4401 Q1 TO-92(TO-92-3) 1 LCSC SEMTECH 2N3904 C118538
19 4.3k R14 AXIAL-0.3 1
20 1.5k R8,R11,R12,R1 AXIAL-0.3 4
21 SYNC P10 HDR-1X1/2.54 1 LCSC ReliaPro Header-Male-2.54_1x1 C81276
22 2k R13,R2,R6 AXIAL-0.3 3
23 RED P11 HDR-1X1/2.54 1 LCSC ReliaPro Header-Male-2.54_1x1 C81276
24 43k R7 AXIAL-0.3 1
25 BLUE P12 HDR-1X1/2.54 1 LCSC ReliaPro Header-Male-2.54_1x1 C81276
26 0.1UF C4 RAD-0.1 1
27 GREEN P13 HDR-1X1/2.54 1 LCSC ReliaPro Header-Male-2.54_1x1 C81276
28 1u C6,C7,C8 CAP-D3.0XF1.5 3
29 TBA530.1 U1 DIP-16 1

Attachments

None

Members

Success
The owner does not allow comments in this project now

Comments (0)
