Breakout board for ADAFRUIT Feather based on MCP2515 CAN controller with an 3.3V CAN transceiver.
This board also connects the various interrupt lines to the Feather to allow for better communication performance especially at higher CAN bus bitrates at the tradeoff that a couple of IO pins are occupied by the CAN FeatherWing. I added 0R resistor bridges into each interrupt line. So if interrupt c...
**There is a newer version of this board available**
Version 2.0: https://easyeda.com/Miraculix200/esp32-s2-test_copy
Breadboard friendly minimal dev board for ESP32-S2 Wrover or Wroom
With MCP1825 voltage regulator (500mA)
Breadboard friendly minimal breakout board for ESP32-S2 Wrover or Wroom
* XC6220 voltage regulator (6V max, 1000mA max, 8uA quiescent current) for battery operation
* All pins except GPIO26
* FTDI header for flashing with FTDI Basic and similar boards
* Uses about 53uA in deep sleep, like the smaller version here: https://easyeda.com/Miraculix200/s2-tiny
Soldering the GND pad in the middle is no...
This shield is designed for easy powering and using two GPIOs of ESP-01/01S module. It is powered by 5 volts DC and has four 3-pin screw terminals for connecting some periphery like 2812 LEDs, relay modules, etc. Also it has a 3.3v power supply on board
ESP8266 ESP-12 minimal stabilized circuit schematic and PCB
With breadboard friendly headers and Wemos D1 mini pin numbers
Designed for battery operation:
MCP1700 or MCP1702 (250mA, 4uA quiescent current)
MCP1825 (500mA, 220uA quiescent current)
VIN: max. 6V
It will also work without the capacitors, but the voltage regulator will be less stable.
You can also solder a...
**ESP WROOM 32 Breakout**
A breakout board for Espressif's ESP32 module ESP-WROOM-32.
The ESP32 is a powerful and low-cost Wifi/Bluetooth chip that enables great Internet-Of-Things applications.
Studio Sophisti is using this chip in several projects,
including a work-in-progress redesign of Ping
The ESP-WROOM-32 can be purchased directly from Espressif or from a distributor like Adafruit: htt...
**Port breakout board for the generic STM32 'Blue Pill' development boards**
*May also support Red/Black Pill boards where pinout/size is compatible with the Blue Pill board.*
**This is a hobby project and comes with no official support. The PCB schematic and board design files are offered 'as is' with no claims made about their fitness for any specific purpose. Use at your own risk.**
A plug-in PCB for the ZX Spectrum that can be populated with your own project.
Design notes at: https://github.com/linker3000/ZX-Spectrum-Breakout-Board
A design to break out the dual micro HDMI ports out to a panel adjacent to the USB/Ethernet ports.
All traces are length matched on high speed differential signals.
This design has not been tested yet, it is currently in production (04/2020)
This has been deisgned to use the BossCon HDD-M-CN09 micro HDMI board edge connectors. Other types will not fit as they all have slightly varying pin spac...
SC115 v1.0 (www.scc.me.uk)
Prototyping breakout module for RC2014
- Easy access to all bus signals
- Flexible address decoding generates /IOWR, /IORD and /IOEN
- Connection to solderless breadboards with Dupont cables
Documentation at [www.scc.me.uk](http://www.scc.me.uk)
This is a breakout board for attaching ZIF-50 connector with a breadboard.
I use it to connect EastRising displays to a breadboard, using [this](https://www.buydisplay.com/default/50-pin-0-5mm-pitch-top-contact-zif-connector-fpc-connector) or [this](https://www.buydisplay.com/default/50-pin-0-5mm-pitch-bottom-contact-zif-connector-fpc-connector) connector.
Reflowing these connectors successfuly...
