【Forecast】3D model preview is coming soon
688 14
UserSupport 4 months ago
Just 3D model preview, 3D file export feature is not start yet, it will be supported next few release later. Just support to import 3D model file, without 3D file design. such as: Kicad wrl, step, obj. ![图片.png](//image.easyeda.com/pullimage/GiZNeqMXkWbZAfmyRMfgYllkSNnp2RCrsOR3kIll.png)
Comments
cjohnson 4 months ago
Wow! This will be very useful. Thank you for the continued development and support.
Reply
phamduyscb 4 months ago
great. if can insert a clear image to pcb layout, i think this soft so very very great
Reply
cjohnson 3 months ago
@phamduyscb You can already do that, File -> Import -> Image
Reply
DJDevon3 3 months ago
Awesome. It can really help to see the assembled view in 3D for height clearances.  Hard to know those things without looking at the datasheet for every single component and that gets really old really quick living the life of a datasheet reader than a designer. :)
Reply
phamduyscb 3 months ago
@cjohnson you dont understand me ![Untitled.png](//image.easyeda.com/pullimage/dCqO04CTjvrriTg7qS1PtZxzR21YSBpHDDaMar9Q.png)
Reply
cjohnson 3 months ago
@phamduyscb What exactly are you trying to do? The import tool works great for importing images to a PCB. ![image.png](//image.easyeda.com/pullimage/uf1KauCWi2MFDOiSKUsCCpacTJj4qepFZM1A0VPx.png) ![image.png](//image.easyeda.com/pullimage/cCINxsq91gmUy45FeQExVss463uzAf5fd0e79ubZ.png)
Reply
phamduyscb 3 months ago
@cjohnson can you import this file? ![44049117_2102429516486460_3091286446254850048_n.jpg](//image.easyeda.com/pullimage/YE1C8xsL6ta0jmIF0ZtBzMfZB2XeLNTNHO9Awsvp.jpeg)
Reply
Daniel Paradinha 3 months ago
@pharmduyscb Yes, but you need to separate the silk screen part of the image from the traces them import them separately and put them on their respective layers.
Reply
cjohnson 3 months ago
@daniel.paradinha I created a separate thread to show him this: [https://easyeda.com/forum/topic/Insert-PCB-as-Image-to-PCB-b26e11571c184ced9e5865e716fbc660](https://easyeda.com/forum/topic/Insert-PCB-as-Image-to-PCB-b26e11571c184ced9e5865e716fbc660)
Reply
neutronstriker 2 months ago
Can we export the 3d model into step/stp file with assembly information? Thanks
Reply
UserSupport 2 months ago
@neutronstriker the alpha version witch 3D model at v6.2 doesn't support this option, it will be supported at 6.3 or 6.4
Reply
neutronstriker 2 months ago
@UserSupport Thanks for update
Reply
MarcC137 2 weeks ago
@UserSupport When I press export svg or easyeda file support I get a pop up saying copy the code in the box, but no code is showing
Reply
UserSupport 2 weeks ago
@MarcC137 That export option is a bug, it should be removed. we will support export 3D model in the future.
Reply
